The HART475 Field Communicator is a handheld communicator that supports HART protocol devices. It is mainly used for configuring, managing, maintaining, adjusting HART intelligent instruments in industrial sites and monitoring instruments during operation.
The HART475 Field Communicator can communicate with 1151, 3051, EJA, ABB, and other HART protocol instruments. It is fully compatible with various intelligent pressure (temperature) transmitters, and can also communicate with electromagnetic flowmeters, V-cone flowmeters, target flowmeters, vortex flowmeters, and other flowmeters that support HART protocol.
Features of HART475 Field Communicator
- During online monitoring and communication, the modulated signal will not interrupt the 4~20mA DC signal;
- The HART communicator can be shared with instruments using HART communication protocol and can be used with all instruments using HART communication protocol;
- Easy to operate Large display screen, users can see at a glance, easy to set and change;
- Information self-diagnosis/protection function;
- Full-featured communication: communication supports flow meters, temperature meters, and transmitters carrying HART protocol;
- Large-screen display: the display interface is larger and clearer, using LCD screen;
- Production testing, diagnosis and inspection of HART smart devices;
- It can configure, calibrate, diagnose, maintain and monitor HART intelligent equipment in field operation;
- Obtain the manufacturer information of the field HART instrument;
- Understand the working status and fault information of the HART instrument;
- Read the output current and process variables of the instrument;
- Obtain the parameters and output values of related sensors;
- Self-checking function;
- format password protection;
- Low voltage alarm display;
- Standard technical specifications;
What’s in the Box
- The device is equipped with:
- A manual operator
- A Battery
- A Pack
- A charger
- A communication cable
- A 250-ohm resistor
Configuration parameters
| Product name: | HART475 English Communicator (Field Communicator) |
| Protocol version: | HART475 |
| Compatible Versions: | HART275/HART375/HART475 |
| Communication object: | It can communicate with 1151,3051, EJA, ABB, and HART protocol imported instruments in terms of flow and various smart transmitters made in China with HART protocol |
| Accuracy class: | 0.05%F.S |
| Battery storage: | -20~50℃ |
| Operating temperature: | -10~50℃ |
| Relative humidity: | 0~95%RH (no condensation) |
| Product Weight: | 0.48Kg |
| Dimensions: | 230*130*45mm |
| Power supply: | Built-in rechargeable battery |
| Packing: | With carrying case |
| Accessories: | Charger,test lead,alligator clip,2500 resistor |
More Featured Products can work with HART Communicators:
Now, Emerson stopped all the services of the 375. You can consider buying a new version-Emerson AMS TREX Device Communicator.
If you need the datasheet, price, or more information about HART 375 Field Communicator,
Just Contact Us.
