Density meter for liquids is a high-precision density meter based on the principle of vibration. Adopt split design. Submersible density meters can be widely used in closed or open tanks, tanks, diversion channels and open channels. Split Type Density Meter for Liquids is also widely used in the detection of sediment content in hydrological stations. Generate corresponding 4-20mA analog signal according to the change of medium density. At the same time, the digital signal can be converted and output to facilitate remote calibration and monitoring. Depending on the industrial process, density can be expressed in: Brix degrees, GL degrees, Baume degrees, Plato degrees and percent concentration.
Features of Split Type Density Meter for Liquids
- Input design, easy to use
- Continuous online monitoring
- Temperature compensation
- Integrated design, maintenance-free
- IP68 waterproof design, suitable for deep water measurement
- Explosion-proof design, convenient for use in special industries
Technical Parameters
| Measuring range: | 0 – 3 g/cc (0 – 3000 kg/m3) |
| Calibration range: | 0.6 – 1.25 g/cc (600 – 1250 kg/m3) |
| Measurement accuracy: | ± 0.001 g/cc (± 1 kg/m3) |
| Repeatability: | ± 0.0001 g/cc (± 0.1 kg/m3) |
| Operating temperature range: | -50℃ ~ +200℃ |
| Maximum working pressure: | 20Mpa |
| Fluid Viscosity Range: | 0 – 20000 cP |
| Temperature coefficient: | 0.1 kg/m3/℃ (after correction) |
| Pressure Effect: | Negligible |
| Built-in temperature sensor: | PT100 |
| Wetted material: | Stainless steel, Hastelloy C22, manganese alloy 400, titanium alloy, etc. |
| Fork Coating: | Standard, PTFE or Electropolished |
| Power supply: | 20 – 28 VDC, 35 – 45 mA |
| Analog output: | 4 – 20 mA, isolated, not self-powered |
| Output accuracy (20°C): | ± 0.1% of reading or ± 0.05% FS |
| Output repeatability (-40 ~ +85°C): | ± 0.05% FS |
| Protection class: | IP65 |
| Shell: | Aluminum alloy |
Technical advantages:
- Direct density or concentration readings, available engineering units include: g/cm3, kg/m3, specific gravity, °Brix, °Baume, °Plato, °GL, percent solids, etc.;
- Suitable for flowing or static liquids;
- Suitable for pipeline and tank density measurement;
- Integrated structure, no moving parts;
- Standard industrial and hygienic process connections;
- The instrument has a built-in temperature sensor to provide accurate temperature compensation;
- Online remote calibration, digital local display;
- Factory multi-point linear correction, higher precision;
- On-site recalibration: no standard reference source, no experimental calibration, no process interruption;
- The converter is compatible with three installation methods: wall-mounted, embedded, and desktop;
Split Type Density Meter for Liquids Applications
Split type density meter for liquids can be widely used in closed or open tanks, tanks, diversion channels and open channels.
Density meter for liquids is also widely used in the detection of sediment content in hydrological stations. In the petrochemical industry, brewing industry, food industry, pharmaceutical industry and mineral processing (such as clay, carbonate, silicate, etc.), it is specifically used for interface detection in multi-product pipelines in the above industries, density detection of stirred mixtures . Reactor endpoint monitoring, separator interface detection.
Application industry
- Measurement of Lime Slurry Density and Concentration in Desulfurization Industry
- Density and concentration measurement of ammonia water in the denitrification industry
- Density and concentration measurement of pulp in mineral processing industry
- Density and concentration measurement of proportioning liquids in the surface treatment industry
- Density and concentration measurement of slime during coal conveying
- Density and concentration measurement of syrups
- Density and concentration measurement of starch emulsions
- Density and concentration measurement of medicinal liquids and concentrates in the pharmaceutical industry
- Density and concentration measurement of chemical reagents such as alcohol and chemical liquids
- Density and concentration measurement of petroleum and oil-synthetic products
FAQ
More Density meter and measurement analysis solution
What Is Density Meter? and Types
Ultrasonic Level Transmitter Installation Guide
Liquid Level Sensor Probes Types and How to Select
What Is the Ultrasonic CO2 Level Indicator? CO2 Bottle Level Measuring Device
Dew Point Monitor for the Fruit and Vegetable Industry
Radar Level Gauge – Everything You Should Know and Selection List
The Split Type Density Meter for Liquids can measure the density or concentration of any liquid and also output density, concentration, Baume and temperature simultaneously.
Density Meter for Liquids is an instrument for measuring fluid density using the principle of vibration. It is used to measure fluid density in real time. Fluid density directly depends on the vibration frequency of the fork. At the same time, a temperature sensor provides temperature compensation, and performs pressure compensation and viscosity compensation for the pressure value before leaving the factory.
Split Type Density Meter for Liquids is widely used in reaction kettle, liquid separation, desulfurization and denitrification, ammonia gas recovery, ammonia production, mixing and stirring, petroleum and petrochemical, brewing equipment, food processing, extraction and concentration of traditional Chinese medicine, acid preparation, etc.
We, Sino-Inst, manufacture and supply Split Type Density Meter for Liquids. Our Split Type Density Meter for Liquids is widely exported to various countries. Including the United States, Britain, Australia and other countries. If you need Density Meter for Liquids, please contact our sales engineers!
